Product Details
Place of Origin: China
Certification: ISO 9001
Payment & Shipping Terms
Minimum Order Quantity: 20
Price: Negotiable
Payment Terms: L/C, T/T, Western Union, Paypal, Money Gram
Supply Ability: 1000000/Month
Model NO.: |
HFE23 |
Theory: |
Electromagnetic Relay |
Usage: |
Car Relay, Household Appliances Relay, Communication Relay, Lathe Relay |
Phase: |
1 |
Electricity Type: |
Dc |
Number Of Pole: |
1 |
Load: |
High Power Relay |
Protective Characteristics: |
Open Relay |
Action Principle: |
Electronic Type |
Size: |
Miniature |
Type: |
Electric Parameter Relay |
MOQ: |
200 |
Trademark: |
YZ |
Transport Package: |
Cartons |
Specification: |
115x54x24 Mm |
Origin: |
China |
HS Code: |
8536411000 |
Port: |
Xiamen, China |
Model NO.: |
HFE23 |
Theory: |
Electromagnetic Relay |
Usage: |
Car Relay, Household Appliances Relay, Communication Relay, Lathe Relay |
Phase: |
1 |
Electricity Type: |
Dc |
Number Of Pole: |
1 |
Load: |
High Power Relay |
Protective Characteristics: |
Open Relay |
Action Principle: |
Electronic Type |
Size: |
Miniature |
Type: |
Electric Parameter Relay |
MOQ: |
200 |
Trademark: |
YZ |
Transport Package: |
Cartons |
Specification: |
115x54x24 Mm |
Origin: |
China |
HS Code: |
8536411000 |
Port: |
Xiamen, China |
| Item | HFE23 relay | ||
| Fall-Protect | Action Angle:30-50°;Reset Angle:>15°;The Error of Action Angle:±5° | ||
| Operating Frequency | Mechanical 60 cycles/min;Electrical 6 cycles/min | ||
| Contact Resistance | 30MΩ(500VDC) | ||
| Test Voltage | Between terminals of the same polarirty | AC1000V,50/60Hz,1min | |
| Between current-carrying metal And ground(case),and between Each terminal and non-carrying metal parts | AC2000V,50/60Hz,1min | ||
| Vibration resistance | 10-55Hz,1.5mm Double amplitude | ||
| Shork Resistance | Let switch fall freely from 200mm high into the cement flool or Armor plate horizontal. One time,one side(Up,dowm,left,right,front,back) | ||
| Life Expectancy | Mechnical>=5000000 cycles Electrical>=10000 cycles | ||
| Degree of protection | IEC IP40 | ||
| Degree of protection against electric shock | Class I | ||
| PTI(Tracking Resistance) | 175 | ||
| Ambient air temperature | 125 ºC 60%RH below(No ice and dew) | ||
| Ambient air humidity | 85% Rhbelow(about +5~+35 ºC) | ||
| Weight | Approx.39.7g | ||
