Product Details
Place of Origin: China
Certification: ISO 9001
Payment & Shipping Terms
Minimum Order Quantity: 20
Price: Negotiable
Payment Terms: L/C, T/T, Paypal
Supply Ability: 1000sets/Day
Model NO.: |
YZ-800KG-1P |
Number Of Stator: |
Single-Phase |
Function: |
Driving, Control |
Casing Protection: |
Closed Type |
Brand: |
Universal |
Theory: |
Garage Opener |
Voltage Input: |
230V AC |
Type: |
AC Motor |
Phase: |
Single Phase |
OEM: |
Acceptable |
Motor Species: |
Asynchronous Motor |
Horsepower: |
Strong Power Output |
Feature: |
Remote Control |
Uplift Weight: |
800kg |
Trademark: |
YZ |
Specification: |
ISO9001 |
Origin: |
Fujian |
HS Code: |
85015200 |
Transport Package: |
Standard Packing |
Model NO.: |
YZ-800KG-1P |
Number Of Stator: |
Single-Phase |
Function: |
Driving, Control |
Casing Protection: |
Closed Type |
Brand: |
Universal |
Theory: |
Garage Opener |
Voltage Input: |
230V AC |
Type: |
AC Motor |
Phase: |
Single Phase |
OEM: |
Acceptable |
Motor Species: |
Asynchronous Motor |
Horsepower: |
Strong Power Output |
Feature: |
Remote Control |
Uplift Weight: |
800kg |
Trademark: |
YZ |
Specification: |
ISO9001 |
Origin: |
Fujian |
HS Code: |
85015200 |
Transport Package: |
Standard Packing |
| Model No. | Max upgrade weight(kg) | Max upgrade height(M) | Power (W) | Current Rating(A) | Output Torque(N.m) | Rotation (r/min) | CHAIN NO. |
| 220V 50Hz(230V 60Hz) | |||||||
| YZ300-1P | 300 | 6.5 | 250 | 3.3 | 168 | 6.2 | 10A |
| YZ500-1P | 500 | 6.5 | 250 | 3.9 | 343 | 6.2 | 10A |
| YZ600-1P | 600 | 6.5 | 370 | 3.9 | 412 | 6.2 | 10A |
| YZ800-1P | 800 | 7 | 370 | 4.5 | 607 | 3.4 | 10A |
| YZ1000-1P | 10000 | 7 | 400 | 4.5 | 1102 | 3.2 | 10A |
| 380V 50Hz(380V 60Hz) | |||||||
| YZ300-3P | 300 | 6.5 | 180 | 1.2 | 168 | 6.2 | 10A |
| YZ500-3P | 500 | 6.5 | 250 | 1.3 | 343 | 6.2 | 10A |
| YZ600-3P | 600 | 6.5 | 250 | 1.3 | 412 | 6.2 | 10A |
| YZ800-3P | 800 | 7 | 300 | 2 | 607 | 3.4 | 10A |
| YZ1000-3P | 1000 | 8 | 400 | 2.3 | 1102 | 6.5 | 12A |
| YZ1300-3P | 1300 | 8 | 600 | 3 | 1372 | 6.5 | 12A |
| YZ1500-3P | 1500 | 8 | 600 | 3.2 | 1610 | 5.7 | |
