Product Details
Place of Origin: China
Brand Name: Universal
Certification: ISO 9001
Payment & Shipping Terms
Minimum Order Quantity: 20
Price: Negotiable
Payment Terms: L/C, T/T, Paypal, Western Union
Supply Ability: 2000 Sets/Day
Model NO.: |
YZ-600kg-1P |
Application: |
Industrial |
Speed: |
Low Speed |
Number Of Stator: |
Single-Phase |
Function: |
Driving, Control |
Casing Protection: |
Protection Type |
Number Of Poles: |
4 |
Starting Mode: |
Variable Frequency Starting |
Brand: |
Universal |
The Theory: |
Roller Door Motor |
Max Upgrade Weight Of Shutter Motor: |
300kg |
Max Upgrade Height Of Shutter Motor: |
6.5m |
Motor Species: |
Asynchronous Motor |
Charateristic: |
Compact And Vogue |
Drive: |
Electricity Supply |
Trademark: |
Universal |
Specification: |
23"*20"*15" |
Origin: |
Fujian Xiamen |
HS Code: |
850140000 |
Transport Package: |
Standard Export Packing |
Model NO.: |
YZ-600kg-1P |
Application: |
Industrial |
Speed: |
Low Speed |
Number Of Stator: |
Single-Phase |
Function: |
Driving, Control |
Casing Protection: |
Protection Type |
Number Of Poles: |
4 |
Starting Mode: |
Variable Frequency Starting |
Brand: |
Universal |
The Theory: |
Roller Door Motor |
Max Upgrade Weight Of Shutter Motor: |
300kg |
Max Upgrade Height Of Shutter Motor: |
6.5m |
Motor Species: |
Asynchronous Motor |
Charateristic: |
Compact And Vogue |
Drive: |
Electricity Supply |
Trademark: |
Universal |
Specification: |
23"*20"*15" |
Origin: |
Fujian Xiamen |
HS Code: |
850140000 |
Transport Package: |
Standard Export Packing |
| Model No. | Max Upgrade Weight (KG) | Max Upgrade Height (M) | Power (W) | Current Rating (A) | Output Torque (N.m) | Rotation(r/min) | Chain NO. | ||
| 220V 50Hz (230V 60Hz) | |||||||||
| YZ-300-1P | 300 | 4.5 | 180 | 2.2 | 168 | 3.8 | 08B | ||
| YZ-500-1P | 500 | 6 | 370 | 3.5 | 345 | 5.9 | 10A | ||
| YZ-600-1P | 600 | 6 | 370 | 3.5 | 412 | 5.2 | 10A | ||
| YZ-800-1P | 800 | 6 | 400 | 4.2 | 650 | 4.8 | 10A | ||
| YZ-1000-1P | 1000 | 10 | 800 | 5.8 | 810 | 4.2 | 10A | ||
| 380V 50Hz (380V 60Hz) | |||||||||
| YZ-800-3P | 800 | 6 | 370 | 1.3 | 650 | 4.8 | 10A | ||
| YZ-1000-3P | 1000 | 10 | 400 | 1.5 | 810 | 4.2 | 12A | ||
| YZ-1300-3P | 1300 | 10 | 800 | 2.0 | 1050 | 4.2 | 12A | ||
| YZ-1500-3P | 1500 | 10 | 800 | 2.5 | 1220 | 3.8 | 12A | ||
