Product Details
Place of Origin: China
Certification: ISO 9001
Payment & Shipping Terms
Minimum Order Quantity: 20
Price: Negotiable
Payment Terms: L/C, T/T, D/P, Western Union, Paypal, Money Gram
Supply Ability: 2000 PCS/Day
Model NO.: |
V-16TA |
Pressing Type: |
Push-Button |
Number Of Switch: |
Single Control Switch |
Protection: |
Waterproof |
Size: |
Normal Size |
Environment: |
﹤250℃ |
Breaking Capacity: |
General Type |
Breaking Form: |
Single Type |
Application: |
Room Heater |
Brand: |
Yuzhou |
Trademark: |
Universal |
Transport Package: |
Standard Export Packing |
Specification: |
ISO |
Origin: |
Fujian, Xiamen |
Port: |
Xiamen, China |
Model NO.: |
V-16TA |
Pressing Type: |
Push-Button |
Number Of Switch: |
Single Control Switch |
Protection: |
Waterproof |
Size: |
Normal Size |
Environment: |
﹤250℃ |
Breaking Capacity: |
General Type |
Breaking Form: |
Single Type |
Application: |
Room Heater |
Brand: |
Yuzhou |
Trademark: |
Universal |
Transport Package: |
Standard Export Packing |
Specification: |
ISO |
Origin: |
Fujian, Xiamen |
Port: |
Xiamen, China |
Operating Speed | 0.1mm~1m/s(Related with actuator forms) |
Operating Frequency | Mechanical 60 cycles/min;Electrical 30 cycles/min |
Insulation Resistance | >=100 MΩ (500VDC) |
Contact resistance | <=30mΩ(Initial value) |
Between terminals of the same polarirty | AC1000V,50/60Hz,1min |
Between current-carrying metal And ground(case),and between Each terminal and non-carrying metal parts | AC3750V,50/60Hz,1min |
Vibration resistance | 10-55Hz,1.5mm Double amplitude |
Shork Resistance | Destruction : OF>0.5N:1000m/s ²(approx.100G)max OF<=0.5N:500m/s ²(approx.50G)max Malfunction: OF>0.5N:300m/s ²(approx.30G)max OF<=0.5N:200m/s ²(approx.20G)max |
Life Expectancy | Mechnical>=5000000 cycles Electrical>=100000 cycles |
Degree of protection | IEC IP67 |
Degree of protection against electric shock | Class I |
PTI(Tracking Resistance) | 175 |
Ambient air temperature | 125 Degree 60%RH below(No ice and dew) |
Ambient air humidity | 85% Rhbelow(about +5~+35 Degree) |
Weight | Approx.5.95g(No lever) |
Operating Speed | 0.1mm~1m/s(Related with actuator forms) |
Operating Frequency | Mechanical 60 cycles/min;Electrical 30 cycles/min |
Insulation Resistance | >=100 MΩ (500VDC) |
Contact resistance | <=30mΩ(Initial value) |
Between terminals of the same polarirty | AC1000V,50/60Hz,1min |
Between current-carrying metal And ground(case),and between Each terminal and non-carrying metal parts | AC3750V,50/60Hz,1min |
Vibration resistance | 10-55Hz,1.5mm Double amplitude |
Shork Resistance | Destruction : OF>0.5N:1000m/s ²(approx.100G)max OF<=0.5N:500m/s ²(approx.50G)max Malfunction: OF>0.5N:300m/s ²(approx.30G)max OF<=0.5N:200m/s ²(approx.20G)max |
Life Expectancy | Mechnical>=5000000 cycles Electrical>=100000 cycles |
Degree of protection | IEC IP67 |
Degree of protection against electric shock | Class I |
PTI(Tracking Resistance) | 175 |
Ambient air temperature | 125 Degree 60%RH below(No ice and dew) |
Ambient air humidity | 85% Rhbelow(about +5~+35 Degree) |
Weight | Approx.5.95g(No lever) |
