Product Details
Place of Origin: China
Certification: ISO 9001
Payment & Shipping Terms
Minimum Order Quantity: 20
Price: Negotiable
Payment Terms: L/C
Supply Ability: 5000sets/Day
Model NO.: |
YJS |
Structure: |
Wheeled |
Driving Type: |
Electromechanical |
Electric Current Type: |
AC |
Brand: |
Universal |
The Theory: |
Sliding Door Motor |
Motor Capacity: |
500kg |
Position: |
Industrial |
Type: |
Sliding |
Material: |
Iron+Plastic Cover |
Surface Finishing: |
Finished |
Color: |
Black And White |
Function: |
Driving, Control |
Trademark: |
Universal |
Transport Package: |
Standard Export Packing |
Specification: |
RoHS |
Origin: |
Xiamen, Fujian |
HS Code: |
8501400000 |
Port: |
Xiamen, China |
Model NO.: |
YJS |
Structure: |
Wheeled |
Driving Type: |
Electromechanical |
Electric Current Type: |
AC |
Brand: |
Universal |
The Theory: |
Sliding Door Motor |
Motor Capacity: |
500kg |
Position: |
Industrial |
Type: |
Sliding |
Material: |
Iron+Plastic Cover |
Surface Finishing: |
Finished |
Color: |
Black And White |
Function: |
Driving, Control |
Trademark: |
Universal |
Transport Package: |
Standard Export Packing |
Specification: |
RoHS |
Origin: |
Xiamen, Fujian |
HS Code: |
8501400000 |
Port: |
Xiamen, China |
Installation instructions
There is usually an operation button box set beside the door, which can open, stop and close the door body by controlling the buttons above the button box.And it can stop itself when the door body runs to the set position.
Usage
Sliding gate motor can be used in the market a variety of existing translation doors.The product is designed to be suitable for any residential or commercial premises, such as a light load garden gate or a heavy load factory gate. The convenient way to open the door is popular with the public.
Model | YZ-400KG | YZ-500KG | YZ-600KG | YZ-800KG | YZ-1000KG | YZ-1500KG | YZ-2000KG |
Voltage | AC 220V/50Hz; AC 110V/60Hz | ||||||
Max gate weight | 400KG | 500KG | 600KG | 800KG | 1000KG | 1500KG | 2000KG |
Power | 250W | 280W | 370W | 380W | 400W | 550W | 750W |
Out Torque(N,m) | 14N.m | 20N.m | 22N.m | 27N.m | 27N.m | 38N.m | 45N.M |
Work Duty | S2 20min | S2 20min | S2 20min | S2 20min | S2 15min | S2 15min | S2 15min |
Limit Switch | spring limit switch /magnetic limit switch | ||||||
Gate Moving Speed | 11-13M/min | ||||||
Remote Control Range | ≥30M | ||||||
Frequency | 433.92MHz | ||||||
Noise | ≤58dB | ||||||
Temperature | -20ºC~70ºC | ||||||
Driving Mode | Gear | ||||||
Motor speed | 1400R/min | ||||||
